12.6 Inch AMOLED Display 1600x2560 MIPI For Notebook And Pad
$199.95
Sale price
$199.95
Regular price
The 12.6 inch AMOLED display is a rigid AMOLED panel with 1600×2560 resolution and Real RGB pixel arrangement, delivering exceptional color accuracy with 16.7M colors and an ultra-high contrast ratio of 100,000:1. Featuring a MIPI 4-lane interface and integrated touch panel, it is engineered for premium tablets, notebooks, and pad devices that demand vivid visuals and responsive touch performance.
Features
- Ultra-High Contrast & Vivid Color — 100,000:1 contrast ratio with 16.7M colors (RGB 8-bit) and Real RGB pixel arrangement for accurate, lifelike imagery
- High Resolution & Sharp Display — 1600×2560 resolution on a 12.6" panel with 239 PPI pixel density for crisp text and detailed visuals
- Integrated Touch Panel & MIPI Interface — Built-in capacitive touch panel with MIPI 4-lane interface for seamless integration into tablets and notebooks
- Wide Operating Temperature Range — Reliable performance from -20°C to 70°C, suitable for demanding industrial and consumer environments
Applications
Tablet, Notebook and Pad
Mechanical Data
| Parameter | Specification |
|---|---|
| Diagonal Size | 12.6 inch |
| Display Mode | Rigid AMOLED |
| Display Color | 16.7M (RGB × 8-bit) |
| Display Format | 1600 RGB × 2560 |
| Pixel Arrangement | Real RGB |
| Interface | MIPI 4 lanes |
| Collocation IC | RM69380 (COF) / RM692E6 |
| Panel Dimension | 275.411 × 175.232 × 0.6 mm |
| Active Area | 271.4112 × 169.632 mm |
| Pixel Pitch | 106.02 × 106.02 μm |
| Glass Thickness | 0.3 / 0.3 mm |
| Weight | 167.54 g |
| Brightness | 440 cd/m² |
| Contrast Ratio | 100,000:1 |
| Refresh Rate | 60 Hz |
| Pin | 51 Pins |
| Touch Panel | Yes |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 80°C |
Mechanical Drawing
Module Interface
Module Overview
